504 Log Grapple Wheeled Tractor

Tractors 504 Series

504 Log Grapple

504 Log Grapple Wheeled Tractor

Wheeled Tractor

The 504 fitted with a log grapple loader for handling logs, bales and bulky loads.

Log grapple loader · 36.8 kW

Rated power
36.8 kW
Engine model
Weifang 490
Machine mass
2,080 kg
Request a quote WhatsApp
  • Quoted on inquiry, with the full specification in writing.
  • Stock arrives from the factory at our 2000 Plaza, Mombasa Road showroom, where you can see and test it before delivery is arranged.
  • Wear parts — film, blades, belts, rollers and dies — supplied for the life of the machine.

Ask for the 504 Log Grapple technical sheet and working video

Technical data

Full specification

Every figure the factory publishes for this model.

504 Log Grapple — published figures

Rated power 36.8 kW
Engine model Weifang 490
Rated engine speed 2400 rpm
Fuel Diesel
Overall length 4.30 m
Overall width 1.50 m (adjustable)
Overall height 1.96 m
Front wheel spacing 0.96–1.30 m
Rear wheel spacing 0.96–1.30 m
Wheelbase 1.80 m
Ground clearance 300 mm
Machine mass 2,080 kg
Tyres – front / rear 6.50-16 / 11.2-24
Optional tyres 7.50-16 / 11.2-28
Steering system Hydraulic steering
Clutch system 10 in single-acting; 9 in dual-acting (500)

Confirmed at quotation

Voltage and frequencySet to your market at order
PackingExport crate dimensions and gross weight
Container loadingMachines per 20 ft / 40 ft container
Lead timeFrom deposit to shipment
Spare and wear partsFirst set quoted with the machine

No price is published on this site. The machine, its die or wrapping specification, the parts included and the shipping arrangement decide the figure, so every model is quoted in writing on inquiry.

Ordering

What a quotation for the 504 Log Grapple covers

Machinery bought across a border is bought on the paperwork. All three are stated in writing before you commit to anything.

1

Specification

Installed power and voltage, bale size and weight, output, machine weight and overall dimensions. Anything shown here as on request is confirmed at this point, not left open.

2

Packing and shipping

Packing method, crate dimensions and gross weight, machines per container, port of loading, and the lead time from deposit to shipment.

3

Terms

Price validity, payment terms, and the wear parts we recommend ordering with the machine.

Working videos, technical sheets and packing photographs for the 504 Log Grapple are sent with the quotation.
